MRCOOL DIY 5th Gen 36K BTU Wall Mount Air Handler, 230V

Name: MRCOOL DIY 5th Gen 36K BTU Wall Mount Air Handler, 230V
Brand: MRCOOL
SKU: DIY-36-HP-WMAH-230D25-O
Price: 1919.94 CAD

Authorized
Dealer· Ships from Canada

$1,919.94 CAD

The indoor unit for a MRCOOL® DIY® 5th Gen system. It mounts on an inside wall, covers up to about 1,550 sq ft, and connects to the outdoor unit with a pre-charged R-454B Quick Connect® line set, so no vacuum pump is needed.

Highlights and what's in the box ↓

Questions before you buy? Call toll-free 1-844-432-2546

This product qualifies for free shipping anywhere in Canada. All orders ship from our warehouse in Ontario.

🛠️

DIY install

🛡️

7-yr warranty

Highlights

Sized for up to ~1,550 sq ft (36,000 BTU)
Listed on NEEP's cold-climate heat pump list
Heat, cool, auto, dry and sleep modes
Follow Me®: the remote senses the temperature where you're sitting
Wi-Fi control through the Smart HVAC app, Alexa and Google Assistant
DIYPro® cable: no electrical conduit needed for the wiring run
MRCOOL warranty: 7 years on the compressor, 5 years on parts

In the box

Wall mount air handler
Wall mounting plate
Wireless remote
DIYPro® cable

Good to know

This is the indoor unit only. Pair it with a matching 36K 5th Gen condenser (230V), sold separately.
Uses R-454B refrigerant, like the rest of the 5th Gen DIY line. It can't be mixed with 4th Gen (R-410A) units or line sets.
Not sure what pairs with what? The System Builder matches indoor units, outdoor units and line sets for you.
